ORIUS ™ 833 User’s Guide Series Rev 3 2-2
Figure 2-1 DigitalMicrograph Workplace
2.2 Camera configuration
If the camera is already configured by a Gatan service engineer, this section can be ignored.
Before starting acquiring images, it is necessary to configure the camera. This process is shown in Figure 2-2.
Toolbar
Image display
Image acquisition tools
Results window
