ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 i
Preface
About this Guide
This ORIUS™ User’s Guide is written to provide a brief description of the camera’s operating principles,
instructions on how to install the camera, and an introduction to imaging in DigitalMicrograph. For additional
discussion of image processing, refer to the DigitalMicrograph User’s Guide.
Preview of this Guide
The ORIUS™ User’s Guide includes the following chapters:
Chapter 0, “Warning”, summarizes proper use and risk of damage to the camera when doing diffraction analysis
Chapter 1, “Quick Reference,” is a brief summary of the steps necessary to operate an ORIUS™ CCD camera.
Chapter 2, “Introduction,” summarizes the features of the ORIUS™ family cameras.
Chapter 3, “Getting Started,” shows the first steps necessary to start the DigitalMicrograph software and prepare
for the acquisition of an image (Gain Normalization and Magnification Calibration).
Chapter 4, “Image Acquisition,” shows the user the most often used floating windows in DigitalMicrograph and
a brief description on how to use them to view, acquire and save an image.
Chapter 5, “Care and Maintenance,” contains some general tips on the care and maintenance of the ORIUS™
camera. It also contains a list of questions that are often asked by users.
Appendix
- Hardware description provides the system requirements and a checklist. A brief description of the basic
working principles of a CCD camera is also given. The pictures of different parts of the camera (camera head,
back and front of the controller, etc.) are shown.
- CE Requirement.
