ORIUS ™ 833 User’s Guide Series Rev 3 III
Figure A2 Controller’s front panel
Figure A3 Controller’s back panel
A3 Installation
If you have not been trained by Gatan then you must not attempt to install the camera. Installation by an
untrained person will invalidate the warrantee and may cause damage to the equipment and injury to the
installer.
Below are figures showing the connections on the system in case something is accidentally disconnected, this
must not be used as an installation guide.
