ORIUS ™ 833 User’s Guide Series Rev 3 X
Model 833 SC200D CCD Camera Specifications
Camera construction
Retractable CCD sensor lens coupled to scintillator.
Camera mounts in TEM 35mm port.
TEM Voltage
200 to 400kV
CCD sensor
Interline, 2048x2048 pixels, each pixel 7.4um x 7.4um
CCD grade
Single
Binning
1,2,4x
Optics
lens
Anti-blooming
On-chip (>100x full well)
Digitization
>30MHz, Fast mode, 14-bit, 5MHz (High-quality mode)
Acquisition speed
30 fps, 4x Binning (512 x 512 pixels), dual-port
15 fps, 4x Binning (512 x 512 pixels), single-port
Dynamic Range
2500:1 (maximum/noise), 4096 grey values
Gain uniformity
< 10% r.m.s. in uncorrected images
Maximum column defects
Total < 10; No adjacent column defects
Exposure settings
100 μs - 30 min
Non-linearity
< 2% to 16000 counts
Realtime Digital Processing
dark-subtraction, gain-normalization, live FFT
Cooling
Regulated Peltier-cooling.
CCD overheat protection
YES
Replaceable scintillator
YES
External shutter
Not required but available at additional cost
Water connection
YES
Computer interface
1394 IEEE
Auto exposure
YES (exposure estimation takes less than 5 sec)
X-ray shielding
PTB standard
EMC compliance
CE (class B) and UL
Installation by Gatan
Required
Computer platform
Windows XP
