Gate Titan User Guide

09
WWW.GATEE.EU
2.1 Specification
TITAN gives you the option to adjust:
•
•
• F
•
Trigger sensitivity
Pre-cocking mode
ire selector mode
Burst mode
Rate of fire
Low battery warning
Battery protection
Time delays between shots (niper delay)
•
•
•
• s
TITAN is compatible with Tactical Programming Card and USB-Link.
They enable (among others) settings adjustment and sensors inspection.
In order to install TITAN, you must learn how to use at least one of them.
WARNING!
PARAMETERS:
Supply voltage:
Current consumption on standby:
Dimensions (max.):
Weight:
3.8-17 V
280 µA (depends on battery type)
47.4 x 28.7 x 13.5 mm [1.9 x 1.13 x 0.53 in]
27.6 g [0.97 oz]
2. TITAN Drop-in Module
USER GUIDE
This version of TITAN is compatible with most V2 gearboxes.
TITAN is an electronic unit installed inside of
a gearbox. It replaces the trigger contacts
and the cut-off lever, which takes control of
your AEG. You can configure your TITAN
using the Tactical Programming Card or
U SB L i nk with G AT E Co ntrol Stati on
computer App.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
