Click the (Setup) button under Linkage to go
to the Linkage setup screen. This sets up the
video display, recording and snapshot options
associated with this alarm.
The Linkage setup screen enables you to
configure the following options:
▪ Channel – checkboxes which allow you
to select any combination of the
camera channels to be included in the
display and recording.
▪ Pre Recording – numeric value box
which allows you to enter the duration
for which video will be recorded prior
to the alarm being triggered.
▪ Post Recording – numeric value box
which allows you to enter the duration
for which video will continue to be
recorded when the alarm is triggered.
▪ Lock – checkbox, if selected will mark
the recorded video associated with this
alarm as locked video.
▪ Linkage IO Output – checkboxes, if
enabled, the device will send a signal
to the selected IO output lines.
▪ Output Delay Time – numeric text
field to set the delay time for the IO
output (in seconds).
▪ Linkage Screen – drop list to select the
options to display the video from the
selected cameras on-screen when the
alarm occurs.
None : Not displayed.
Single : Display 1 camera.
Double : Display 2 cameras.
Quad : Display 4 cameras.
If Single (1x1), Double (2x1), or Quad (2x2)
display is selected, the (Setup) button allows
you to select the layout of the channels to be
displayed on-screen.
The drop lists are shown on-screen accordingly
to the grid layout mode selected. You can easily
choose each individual camera channel to be
displayed in the selected grid segment visually.
