There are numerous customisable options and accessories which can tailor the product installation to
fit your unique operating environment and requirements.
Please contact Gatekeeper Systems for information on optional download kits and other accessories for
use with your product.
2.3 System Specifications
System Specifications
Video
Video Channels
4 Analog High Definition (AHD) channels and 1 IP channel
Output
1 channel
Video Compression
H.265 / H.264
Video Quality
User configurable (1 to 8, 1 is best quality)
Resolution
IP: Camera Dependent
1080p (1920×1080)
720p (1280×720)
AHD:
1080p (1920 x 1080)
720p (1280 x 720)
WD1 (928 x 480), WHD1 (928 x 240), WCIF (464 x 240),
D1 (704 x 480), HD1 (704 x 240), CIF (352 x 240)
NTSC:
WD1 (928×480), WHD1 (928×240),
WCIF (464×240), D1 (704×480), HD1 (704×240),
CIF (352×240)
Video Resource
4 channels @ 15 FPS 1080P (AHD),
1 channels @ 30 FPS 1080P (IPC)
4 channels @ 30 FPS 720P (AHD),
1 channels @ 30 FPS 1080P (IPC)
Video Streams
Dual Streaming
Audio
Input
4 Analog channels and 1 via IP
Output
1 channel
