Y35 HD v3 User Manual & Install Guide
24 of 156
No.
Action
IR Remote
Finger Mouse
ICD2
11
Cycle to the next
channel.
Press the (0) button
on the numeric keys of
the IR Remote.
Not applicable. Use the
on-screen controls.
Press the (0) button on
the numeric keypad of
the ICD2.
12
Playback controls for
video.
When you are viewing
video playback, press
the Setup key to
display/hide the on-
screen video playback
controls which you
then use to adjust the
video playback.
Besides that, you may
also use the following
dedicated keys on the
IR Remote to perform
the following actions:
Pause/Step through
the video frame by
frame.
Play the video at
normal speed.
Slow motion playback
(pressing repeatedly
cycles through the
available slow-motion
speed settings).
Stop the video
playback.
When you are viewing
video playback, press
the Right Button to
display/hide the on-
screen video playback
controls.
You may then use the
on-screen controls to
adjust the video
playback.
When you are viewing
video playback, tap
anywhere on the screen
to display/hide the on-
screen video playback
controls.
You may then use the
on-screen controls to
adjust the video
playback.
3.3 The Y35 HD v3 Start-up Screen Layout
Upon start-up, the screen of the Y35 HD v3 will display the live video streams from the various cameras
attached to the Y35 HD v3. Users can select and configure how many video channels to be displayed
on the screen for monitoring purposes. The screen also serves as an interface into the menu system of
the Y35 HD v3 where users can playback recorded video, and access the configuration menu to change
the device configuration settings.
The screen layout will stay the same regardless of whether an ICD2 is being used, or an LCD monitor
being used along with a Finger Mouse or IR Remote control. This ensures that the user always has a
familiar interface and consistent methodology to interact with the menu system and device functions.
