Operational Method Roller-Type
Max. Cutting Width 600mm (23.6")
Max. Cutting Length 50m (164')
Max. Media Loading Width 719mm (28.3")
Number of Pinch Rollers 3
Material Thickness 0.8mm (0.03")
Drive Motor Stepper motor
Max. Cutting Force 250g
Max. Cutting Speed 552 mm /sec (21.7 ips) (at 45° direction)
Acceleration 0.7 G (gravity)
Offset 0~1.0 mm (with an increase of 0.025mm)
Memory Buffer 1 MB
Interfaces USB 2.0 (Full Speed), Serial (RS-232C)
Type of Command HP-GL, HP-GL/2
Mechanical Resolution 0.012 mm
Software Resolution 0.025 mm
Distance Accuracy ±0.254 mm or ±0.1% of move, whichever is greater
Repeatability ±0.1mm
Curve & Arc Smoothing Yes
Configurable Origin Yes
Test Cut capability Yes
Repeat Yes
Control Panel 2 LEDs/10 Keys
Diameter of Blade 2.5 mm
Power Supply AC 100-240V, 50~60 Hz (auto switching)
Power Consumption 40 watts
Stand Standard
