AR-24 User Manual
Sure Cuts A Lot A-4
Step 4 Adjust Blade Offset, Overcut Value, Multi-Cut and Quality under Cut Settings window
if needed.
*Blade Offset: set the offset value according to different blade, for a
standard blade, set the offset value at 0.25mm, 0.5mm for an optional
advanced blade and 0mm for an optional plotting pen.
*Quality: associated with the cutting result; please note the better
cutting quality, the slower cutting speed.
*Multi-Cut: to repeat the cutting job at same position which is suitable
for cutting thick material.
*Overcut:
allows for easier weeding and makes up for incomplete cut
lines.
