4
1 2 3 4 5 6 7 8
1 1
1 2
1 3
1 4 1 5
1 6
1 7 1 8 1 9 2 0
2 4
V A C
2 4
V A C
G N D
I N T .
B E L L
R T N
I / O
C O M
1
42
3 5
6 M I C
G N D
+ 1 2
V D C
O U T
2 1
2 2
+
I N
I N P U T
7
+
+
H
H
+
+
R G W B
R G W B
6 5 0 m A
6 5 0 m A
L I N E 2
L I N E 1
P A N E L
T E R M I N A L
S T R I P
I / O
C O M
Z O N E 1
1 1
1 2
Z O N E
C O M
Z O N E 1
1 1
1 2
R J - 3 I X
( C A - 7 8 A )
P H O N E
J A C K
R J - 3 I X
( C A - 7 8 A )
P H O N E
J A C K
9
1 0
V O I C E
S I R E N
V O I C E
S I R E N
S
Advent Commercial Fire System
60-562-03-250Z and 60-562-06-132Z
For Supplementary Use Only
Ext. Siren/Horn
Use Onboard Panel Inputs Only For Fire Or Burglary Applications.
Do Not Mix Fire And Burglary Applications.
General Purpose Inputs/Outputs
Listed Panel
Cabinet Tamper Switch
(Normally Closed)
Listed 4 OHM
Speaker For
Fire Protective
Signaling Unit
Note 2:
Listed Output
Device Control
(12 VDC, 200 MA
Max.)
Note 6:
Listed Fire
Pulls
2.0K OHM
EOL Resistor
(Black) 49-467 or 49-454
(at last device)
Use In-and-Out
(Daisy-Chain)
Multiple Device
Wiring Methods
Only
To Additional
Listed Superbus
Touchpads
And/Or
Modules
Built-In
Circuit
Breaker
Note 1:
Class 1 24 VAC
100 VA 60-830
Line
Splice
To 110 VAC 60 HZ
Circuit
Lower
Left
Panel
Mounting
Screw
(Green)
Earth
Ground
Panel SuperBus
Wiring Harness
49-462
Splice
2.0K OHM EOL Resistor (Black)
49-467 or 49-454 (locate at device)
Optional
Listed Touchpad
Enable Keyswitch
(Normally Closed)
Yellow
Not Used
Touchpad
Wiring Harness
49-430
Listed DC
Horn/Strobe(s)
Supplementary
Use Only
2 Conductor
18-Gauge Solid Wire
2.0K OHM
EOL Resistor
49-467 or 49-454
(at last device)
Note 6:
Listed Water
Flow Sensors
Note 4:
Listed 2-Wire
Smoke/Heat
Detector
2 Conductor
18-Gauge Solid Wire
2.0K OHM
EOL Resistor
49-467 or 49-454
(at last device)
2.0K OHM
EOL Resistor
49-467 or 49-454
(at last device)
Use In-and-Out
(Daisy-Chain)
Multiple Device
Wiring Methods
Only
1/2-Inch EMT
Conduit
Phone Line 2
Phone Line 1
Dual Phone
Line Module
60-768
Dual DB-8
Phone
Cord
49-426(3)
Phone
Jack
Phone
Test
Tip/Ring
Lugs
Note 3:
SuperBus Device
Connectors (2)
Primary
Secondary
IMPORTANT!
Connectors For Optional
Listed Panel Input/Output
Expansion SnapCards
IMPORTANT!
Use Bus 1 and Bus 2 Headers
For Only Fire or Burglary
Applications. Do Not Mix Fire
And Burglary Bus Devices On
Either Header.
Also, All Bus Device Inputs
And Outputs Must Be Dedicated
To Either Fire Or Burglary
Applications. Do Not Mix Fire
Inputs and Outputs on Any Bus
Device.
And Burglary Applications On
IMPORTANT!
SnapCard Expansion Slots
Must Be Used For Either Fire
Or Burglary Applications.
Do Not Mix Fire and Burglary
Applications on SnapCard
Inputs and Outputs.
NOTES:
1. The AC power supply is non-power limited. It must be separated from all power limited
wiring by at least 0.25” and wired using a separate knockout.
2. Or to any general purpose I/O terminal programmed as an output. For UL burglary use only.
3. Either connector may be used for connecting up to 31 SuperBus 2000 devices.
4. 2-wire smoke loop compatibility identifier 60-562.
5. See SuperBus 2000 Dual Phone Line Module Installation Instructions (document
number 466-1363) for module and BUS and phone jack wiring details.
6. Or to any general purpose I/O terminal programmed as an input.
SuperBus 2-Line Alphanumeric Touchpad 60-810-4
Black (Gnd)
White (Bus B)
Green (Bus A)
Red (+12 VDC)
All Panel Terminal Connections Except Backup Battery Are Class II Power Limited
Not Used
2-Wire
Smoke Loop
The Following Terminals Are Supervised:
1, 2, 4, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 21, and 22.
The Following Terminals Are Not Supervised:
3, 5, 6, 7, 8, 19, and 20.
2.0K OHM
EOL Resistor (Black)
(at last device)
220 MF
35 V Capacitor
17-101
Load
49-467 or 49-454
To Next Page
