63
Advent Commercial Fire System
Appendix A:
System Configuration Worksheets
Use Table A.1 to determine maximum and standby current
draw based on the devices connected to the panel.
Customer Name _________________________________
Address _______________________________________
City _________________ County ___________ State ___
Zip __________ Phone (____) _______________
Table A.1 System Hardwire Devices
Part No. Description Qty. Standby Current Draw
Standby
Current
Subtotal
Maximum
Current Draw
Maximum
Alarm
Current
Subtotal
Control Panel
60-562-06
60-562-03
Control Panel 500 mA 500 mA 530 mA (No
speakers connected
to terminals 9 and
10)
530 mA
(No
speakers
connected
to terminals
9 and 10)
Hardwire Sensors/Detectors
13-082 PIR Motion Detector 10 mA 10 mA
13-443 2-Wire Smoke Sensor 100 µA N/A
13-444 2-Wire Smoke/Heat Sensor 100 µA N/A
Fire Pull Station N/A N/A
Hardwire Sirens/Speakers
13-046 Hardwire Exterior Siren N/A 145 mA
13-060 8 Ohm, 15W Speaker N/A N/A
SuperBus 2000 Touchpads and Modules (31 Devices per Bus Header)
60-768 SuperBus 2000 Dual Phone
Line Module
20 mA 60 mA
60-783
60-854
SuperBus 2000 Printer
Module
Note
Metal enclosure required for
commercial applications.
35 mA 40 mA
60-783-02 SuperBus 2000 RS 232
Automation Module
35 mA 35 mA
60-803-01 SuperBus 2000 2x20 LCD
Alphanumeric Touchpad
75 mA 120 mA
60-804-01 SuperBus 2000 2x20 VFD
Alphanumeric Touchpad
75 mA 120 mA
60-810-04 SuperBus 2000 2x20 VFD
Fire Alphanumeric Touchpad
75 mA 120 mA
60-821-95
(plastic)
60-856-95
(metal)
SuperBus 2000 RF Commer-
cial Transceiver Module
Note
Metal enclosure required for
commercial applications.
50 mA 50 mA
60-774 SuperBus 2000 8Z Hardwire
Input Module
18 mA 35 mA
60-770 SuperBus 2000 4-Relay
Output Module
25 mA 180 mA
60-870 SuperBus 2000 LED Driver
Board
20 mA 20 mA
60-871
(display)
60-872
(terminal)
SuperBus 2000 LED Display
or Terminal Board
36 mA (1 LED per group) 65 mA
(max LEDs lit)
SnapCards (2 per panel)
To Next Page
