Advent Commercial Fire System
Central Station Burglar-Alarm System Units (UL 1610)
System Setup and Programming
The system Feature Numbers shall be set as follows in
UL 1610 listed systems:
Digital Alarm Communicator System Units (UL 1635)
Same as UL 1610 plus:
A UL Listed Exterior Siren
Central Station Reporting
The panel has been tested with the following central station
receivers using Contact ID reporting format:
ITI CS-5000 Central Station Receiver
Sur-Gard Central Station Receiver with models
SG-DRL2A and SG-CPM2
CSA Certified Accessories
California State Fire Marshall Listed
Installations
The California State Fire Marshall listing has been
approved.
ZONE ATTRIBUTES attribute 4 must be set to off
(47004)
Planning the Installation
This section describes system capabilities to help you get
familiar with the system. “Appendix A” provides planning
sheets with tables that let you record the hardware and pro-
gramming configuration of the system. Fill in all necessary
information ahead of time to help prepare for the installa-
tion, and retain for your records.
Note
It is recommended that no more than 250 wireless fire
sensors (60-849-01-95 or 60-917-95 only) and a maxi-
mum of 132 of all other wireless sensors be used on 250
zone Advent systems.
If 2 Advent systems are in close proximity the total number
of wireless sensors for all systems must not exceed 250
wireless fire sensors or 132 of all other sensors.
Panel Types
To start planing the installation, find your specific panel
type below. The panel type will help determine the system
capabilities (dependent upon devices used).
Panel Components
Before installing devices and making wiring connections,
familiarize yourself with the main panel components. Fig-
ure 1 shows the main component locations for the circuit
board.
47004 Zone Attributes (edit sensors) N/A
xx = Two digit partition number.
yy = Two digit non-pager phone number.
Table 6. UL 1610 Listed System Settings
Feature No. Feature Required Setting
xx002 Siren Time Out 16 min., minimum
xx003 Standard Entry Delay 45 sec., maximum
xx004 Exit Delay 60 sec., maximum
yy004 Communication Format 0 Contact ID
xx088 Report Partition/Area Events
to Central Station
1-On
xx092 Enable Auto Force Arming 0-Off
xx097 Exterior Arming Verification 0-Off
xx098 Audible Verification at Close
Report
1-On
xx102 One-Time Reset Enabled 0-Off
xx108 Enable Daily Reporting of
Partition Trouble
1-On
17034 Phone Test Interval 1 Day
17036 AC Stable Time 90 sec. maximum
17041 Hours to Delay Before
Reporting AC Failure
6-12 hours
17049 RF Supervisory Time A 4 hours
17069 No Phone Line Attached 0-Off
17072 Enable RF Jam Detect 1-On
17073 Battery Test Interval 1-4 hours
17076 Commercial or Residential
Installation
1-Commercial
17078 Detect Receiver Failure 1-On
17079 Alarm Messages Play at High
Vo l um e
1-On High
17096 Report System Events 1-On
47004 Zone Attributes (edit zones) N/A
xx = Two digit partition number.
yy = Two digit non-pager phone number.
Table 5. UL 1023 Listed System Settings
Feature No. Feature Required Setting
Table 7. Advent Commercial Panel Types
Part Number Description
Partitions/Areas
Users
Input Zones
LEDs
250Z, 60-562-03 Commercial Fire
Panel. UL Listings
include 864, 365, 609,
985, 1023, 1610, and
1635. Red enclosure.
8 250 250 512
132Z, 60-562-06 4 100 132 256
To Next Page
