Advent Commercial Fire System
Appendix B: Reference Tables
This appendix contains tables for selecting zone type num-
bers, system features, X10 Module house, unit codes and
responses, SuperBus device unique ID numbers, and text
descriptor numbers. Table notes (if any) appear at the bot-
tom of the last page of the table.
Note
Fire zone types are always active.
Table B.1 Zone Type Characteristics
No. Name Application
Active Level
Alarm/Siren
Delay
Supervisory
Restoral
CS Alarm Report
CS Cancel Report
Bypassable
Chime
Resets Activity Timer
00 Fixed Panic 24-hour audible fixed emergency
buttons.
1, 2, 3, 4, 5 Police/Police Instant
√ √ √ √
01 Portable
Panic
24-hour audible portable
emergency buttons.
1, 2, 3, 4, 5 Police/Police Instant
√ √ √
02 Fixed Panic 24-hour silent fixed emergency
buttons.
1, 2, 3, 4, 5 Police/Silent Instant
√ √ √ √
03 Portable
Panic
24-hour silent portable emergency
buttons.
1, 2, 3, 4, 5 Police/Silent Instant
√ √ √
04 Fixed
Auxiliary
24-hour auxiliary sensor, such as
Pendant Panic or holdup button.
1, 2, 3, 4, 5 Aux./Aux. Instant
√ √ √ √
05 Fixed
Auxiliary
24-hour auxiliary emergency
buttons. Siren shut-off confirms
CS alarm report.
1, 2, 3, 4, 5 Aux./Aux. Instant
√ √ √ √
06 Portable
Auxiliary
24-hour portable auxiliary alert
buttons.
1, 2, 3, 4, 5 Aux./Aux. Instant
√ √ √
07 Portable
Auxiliary
24-hour portable auxiliary button.
Siren shut-off confirms CS alarm
report.
1, 2, 3, 4, 5 Aux./Aux. Instant
√ √ √
08 Special
Intrusion
Special belongings, such as gun
cabinets and wall safes.
1, 2, 3, 4, 5 Police/Police Instant
√ √ √ √ √
09 Special
Intrusion
Special belongings, such as gun
cabinets and wall safes.
1, 2, 3, 4, 5 Police/Police Standard
√ √ √ √ √
10 Entry/Exit
Delay
Entry and exit doors that require a
standard delay time.
2, 3, 4, 5 Police/Police Standard
√ √ √ √ √ √ √
11 Entry/Exit
Delay
Garage doors and entrances that
require an extended delay time. *
2, 3, 4, 5 Police/Police Extended
√ √ √ √ √ √
12 Entry/Exit
Delay
Driveway gates and entrances that
require a twice extended delay
time. *
2, 3, 4, 5 Police/Police Twice
Extended
√ √ √ √ √ √
13 Instant
Perimeter
Exterior doors and windows. 2, 3, 4, 5 Police/Police Instant
√ √ √ √ √ √ √
14 Instant
Interior
Interior doors. 2, 3, 4, 5 Police/Police Follower
√ √ √ √ √ √
15 Instant
Interior
Interior PIR motion sensors. * 2, 3, 4, 5 Police/Police Follower
√ √ √ √ √
16 Instant
Interior
Interior doors. 3, 4, 5 Police/Police Follower
√ √ √ √ √ √
17 Instant
Interior
PIR motion sensors. * 3, 4, 5 Police/Police Follower
√ √ √ √ √
18 Cross Zone
Instant
Interior
PIR motion sensors subject to false
alarms. * †
3, 4, 5 Police/Police Follower
√ √ √ √ √
19 Delayed
Interior
Interior doors that initiate a delay
before going into alarm.*
3, 4, 5 Police/Police Standard
√ √ √ √ √ √
