Advent Commercial Fire System
Determining Maximum Panel Wire Length
Example:
Using 22 gauge wire to connect the following devices on
one wire run (length of cable):
Device Current Draw
(see note)
1- Hardwire 2-Line Alpha Touchpad = 120 mA
1- RF Transceiver Module = 50 mA
1-8Z Hardwire Input Module = 35 mA
Total Device Current Draw = 205 mA
Find the total device current draw in the table and match the
wire type used. In this example, the maximum recom-
mended wire length is about 154 feet. For longer lengths,
use a larger gauge wire.
Note
For self- or remotely-powered devices, the maximum rec-
ommended wire length is 4,000 feet using 22 gauge or
larger wire.
60-756 4 Input/2 Output SnapCard 10 mA
+ 2.5 mA per zone used
+ 7 mA per smoke loop used
+ 34 mA per relay used
185 mA
60-757 8Z Hardwire Input SnapCard 10 mA
+ 2.5 mA per zone used
+ 7 mA per smoke loop used
230 mA
60-758 4 Output SnapCard 6 mA
+ 34 mA per relay used
130 mA
Tota l
To acheive 24-hour backup Total Standby Current Draw must not exceed 650mA with 1 battery, 1350mA with 2 batteries, or
2.0A with 3 batteries for UL systems
Total Maximum Alarm Current Draw (must not exceed 5.5A)
Table A.1 System Hardwire Devices (Continued)
Part No. Description Qty. Standby Current Draw
Standby
Current
Subtotal
Maximum
Current Draw
Maximum
Alarm
Current
Subtotal
Table A.2 Max. Wire Length Recommendations*
(Feet)
Total
Device
Current
Draw
(mA)
22 Gauge
(AWG)
18 Gauge
(AWG)
16 Gauge
(AWG)
14 Gauge
(AWG)
100
616 1,562 2,486 3,936
200
308 782 1,244 1,968
300
206 522 830 1314
400
154 392 622 982
500
124 314 500 792
600
104 262 416 653
700
88 224 356 564
800
78 196 312 492
900
70 174 278 438
1000
61 156 250 394
1100
56 142 226 358
1200
54 130 208 330
1300
48 120 192 304
1400
44 112 178 282
1500
42 104 166 264
1600
40 98 156 246
1700
36 92 146 232
1800
34 88 138 216
1900
32 82 132 208
2000
30 78 126 198
2100
29 74 120 188
2200
28 72 114 180
2300
27 68 108 172
2400
26 66 104 164
2500
25 64 100 158
2600
24 60 96 152
2700
23 58 92 146
2800
22 56 90 140
2900
21 54 86 136
3000
20 52 84 132
*Two volt maximum loop voltage drop.
