GE af-600 fp

Figure 1.4 Compact IP21 (NEMA 1) and IP54 (NEMA 12), Unit
Sizes 41, 42, 43, 44, 51, 52
1) AUX Relay
01 02 03
04 05 06
2) Temp Switch 6) SMPS Fuse (see 12.3 Fuse Tables for part number)
106 104 105 7) AUX Fan
3) Line 100 101 102 103
R S T L1 L2 L1 L2
91 92 93 8) Fan Fuse (see 12.3 Fuse Tables for part number)
L1 L2 L3 9) Mains ground
4) Load sharing 10) Motor
-DC +DC U V W
88 89 96 97 98
T1 T2 T3
Table 1.4
Introduction AF-600 FP Design and Installation Guide
1-4 DET-768A
