GE af-600 fp - Page 122

AF-600 3-
phase
Recommended fuse
size
Recommended max
fuse
[kW]/[HP]
11/15 gG-25
gG-63
15/20 gG-32
18.5/25
22/30 gG-40
30/40 gG-63 gG-80
37/50 gG-100
45/60 gG-80 gG-125
55/75 gG-100 gG-160
75/100 gG-125
90/125
110/150 aR-250 aR-250
132/200 aR-315 aR-315
160/250 aR-350 aR-350
200/300
250/350 aR-400 aR-400
315/450 aR-500 aR-500
400/550 aR-550 aR-550
450/600
aR-700 aR-700
500/650
560/750
aR-900 aR-900
630/900
710/1000
aR-1600 aR-1600
800/1150
900/1250
1000/1350
1200/1600 aR-2000 aR-2000
1400/1900 aR-2500 aR-2500
Table 12.11 525–690 V, IP21/Nema 1 and IP55/Nema 12
Specifications AF-600 FP Design and Installation Guide
DET-768A 12-19
