Recommended max. fuse
AF-600 1-phase AF-600 3-phase SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
[kW]/[HP] [kW]/[HP] Type RK1 Type RK1 Type CC Type RK1
0.75/1 5017906-006 KLS-R-6 ATM-R-6 A6K-10-6
1.5–2.2/2–3 5017906-010 KLS-R-10 ATM-R-10 A6K-10-R
3.7/5 5017906-020 KLS-R-20 ATM-R-20 A6K-20-R
5.5/7.5 5017906-025 KLS-R-25 ATM-R-25 A6K-25-R
7.5/10 5012406-032 KLS-R-30 ATM-R-30 A6K-30-R
11–15/15–20 5014006-040 KLS-R-40 - A6K-40-R
18.5/25 5014006-050 KLS-R-50 - A6K-50-R
7.5/10 22/30 5014006-063 KLS-R-60 - A6K-60-R
11/15 30/40 2028220-100 KLS-R-80 - A6K-80-R
37/50 2028220-125 KLS-R-100 - A6K-100-R
45/60 2028220-125 KLS-R-125 - A6K-125-R
18.5/25 55/75 2028220-160 KLS-R-150 - A6K-150-R
37/50 75/100 2028220-200 KLS-R-200 - A6K-200-R
90/125 2028220-250 KLS-R-250 - A6K-250-R
Table 12.16 380–480 V, 125 HP and below
Recommended max. fuse
AF-600 1-phase AF-600 3-phase Bussmann Ferraz-Shawmut Ferraz-Shawmut Littel fuse
[kW]/[HP] [kW]/[HP] Type JFHR2 Type J
Type JFHR2
1)
Type JFHR2
0.75/1 FWH-6 HSJ-6 - -
1.5–2.2/2–3 FWH-10 HSJ-10 - -
3.7/5 FWH-20 HSJ-20 - -
5.5/7.5 FWH-25 HSJ-25 - -
7.5/10 FWH-30 HSJ-30 - -
11–15/15–20 FWH-40 HSJ-40 - -
18.5/25 FWH-50 HSJ-50 - -
7.5/10 22/30 FWH-60 HSJ-60 - -
11/15 30/40 FWH-80 HSJ-80 - -
37/50 FWH-100 HSJ-100 - -
45/60 FWH-125 HSJ-125 - -
18.5/25 55/75 FWH-150 HSJ-150 - -
37/50 75/100 FWH-200 HSJ-200 A50-P-225 L50-S-225
90/125 FWH-250 HSJ-250 A50-P-250 L50-S-250
Table 12.17 380–480 V, 125 HP and below
1) Ferraz-Shawmut A50QS fuses may substitute for A50P fuses.
Specifications AF-600 FP Design and Installation Guide
12-22 DET-768A
