Recommended max. fuse
AF-600 Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
[kW]/[HP] Type RK1 Type J Type T Type CC Type CC Type CC
0.75/1 KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
1.5–2.2/2–3 KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3.7/5 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5/7.5 KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5/10 KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11–15/15–20 KTS-R-35 JKS-35 JJS-35 - - -
18.5/25 KTS-R-45 JKS-45 JJS-45 - - -
22/30 KTS-R-50 JKS-50 JJS-50 - - -
30/40 KTS-R-60 JKS-60 JJS-60 - - -
37/50 KTS-R-80 JKS-80 JJS-80 - - -
45/60 KTS-R-100 JKS-100 JJS-100 - - -
55/75 KTS-R-125 JKS-125 JJS-125 - - -
75/100 KTS-R-150 JKS-150 JJS-150 - - -
90/125 KTS-R-175 JKS-175 JJS-175 - - -
Table 12.18 525–600 V, 125 HP and below
Recommended max. fuse
AF-600 SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
[kW]/[HP] Type RK1 Type RK1 Type RK1 Type J
0.75/1 5017906-005 KLS-R-005 A6K-5-R HSJ-6
1.5–2.2/2–3 5017906-010 KLS-R-010 A6K-10-R HSJ-10
3.7/5 5017906-020 KLS-R-020 A6K-20-R HSJ-20
5.5/7.5 5017906-025 KLS-R-025 A6K-25-R HSJ-25
7.5/10 5017906-030 KLS-R-030 A6K-30-R HSJ-30
11–15/15–20 5014006-040 KLS-R-035 A6K-35-R HSJ-35
18.5/25 5014006-050 KLS-R-045 A6K-45-R HSJ-45
22/30 5014006-050 KLS-R-050 A6K-50-R HSJ-50
30/40 5014006-063 KLS-R-060 A6K-60-R HSJ-60
37/50 5014006-080 KLS-R-075 A6K-80-R HSJ-80
45/60 5014006-100 KLS-R-100 A6K-100-R HSJ-100
55/75 2028220-125 KLS-R-125 A6K-125-R HSJ-125
75/100 2028220-150 KLS-R-150 A6K-150-R HSJ-150
90/125 2028220-200 KLS-R-175 A6K-175-R HSJ-175
Table 12.19 525–600 V, 125 HP and below
1) 170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator
fuses of the same size and amperage may be substituted.
Specifications AF-600 FP Design and Installation Guide
DET-768A 12-23
