AF-600 3-phase Bussmann Bussmann Bussmann SIBA Littel fuse Ferraz-Shawmut Ferraz-Shawmut
[kW]/[HP] Type RK1 Type J Type T Type RK1 Type RK1 Type RK1 Type J
11/15 KTS-R-30 JKS-30 JJS-30 5017906-030 KLS-R-030 A6K-30R HST-30
15/20 KTS-R-35 JKS-35 JJS-35 5014006-040 KLS-R-035 A6K-35R HST-35
18.5/25 KTS-R-45 JKS-45 JJS-45 5014006-050 KLS-R-045 A6K-45R HST-45
22/30 KTS-R50 JKS-50 JJS-50 5014006-050 KLS-R-50 A6K-50R HST-50
30/40 KTS-R-60 JKS-60 JJS-60 5014006-063 KLS-R-060 A6K-60R HST-60
37/50 KTS-R-80 JKS-80 JJS-80 5014006-080 KLS-R-075 A6K-80R HST-80
45/60 KTS-R-100 JKS-100 JJS-100 5014006-100 KLS-R-100 A6K-100R HST-100
55/75 KTS-R125 JKS-125 JJS-125 2028220-125 KLS-125 A6K-125R HST-125
75/100 KTS-R150 JKS-150 JJS-150 2028220-150 KLS-150 A6K-150R HST-150
90/125 KTS-R175 JKS-175 JJS-175 2028220-200 KLS-175 A6K-175R HST-175
Table 12.20 525–690, IP21/Nema 1 and IP55/Nema 12
Recommended max. fuse
AF-600 Bussmann PN Bussmann PN Siba PN Littlefuse PN
Ferraz-
Shawmut PN
Ferraz-Shawmut PN
[kW]/
[HP]
Type JFHR2 Type JFHR2 Type JFHR2 Type JFHR2 Type JFHR2
110/
150
170M3017 FWH-300 20 610 31.315 L50-S-300 A50-P-300 6.9URD31D08A0315
132/
7.87
[200]
170M3018 FWH-350 20 610 31.350 L50-S-350 A50-P-350 6.9URD31D08A0350
160/
250
170M4012 FWH-400 20 610 31.400 L50-S-400 A50-P-400 6.9URD31D08A0400
200/
300
170M4014 FWH-500 20 610 31.550 L50-S-500 A50-P-500 6.9URD31D08A0550
250/
350
170M4016 FWH-600 20 610 31.630 L50-S-600 A50-P-600 6.9URD31D08A0630
315/
450
170M4017 FWH-800 20 610 32.700 L50-S-800 A50-P-800 6.9URD31D08A0700
355/
500
170M6013 22 610 32.900 6.9URD33D08A0900
400/
550
170M6013 22 610 32.900 6.9URD33D08A0900
450/
600
170M6013 22 610 32.900 6.9URD33D08A0900
500/
650
170M7081
560/
750
170M7081
630/
900
170M7082
710/
1000
170M7082
800/
1200
170M7083
1000/
1350
170M7083
Table 12.21 380–480 V, above 125 HP
Specifications AF-600 FP Design and Installation Guide
12-24 DET-768A
