AF-600 Bussmann PN Rating Alternate Siba PN
[kW]/[HP]
500/650 170M8611 1100 A, 1000 V 20 781 32.1000
560/750 170M8611 1100 A, 1000 V 20 781 32.1000
630/900 170M6467 1400 A, 700 V 20 681 32.1400
710/1000 170M6467 1400 A, 700 V 20 681 32.1400
800/1200 170M8611 1100 A, 1000 V 20 781 32.1000
1000/1350 170M6467 1400 A, 700 V 20 681 32.1400
Table 12.22 380–480 V, Frame Size 6, Inverter Module DC Link Fuses
AF-600
Bussmann PN Alternate External
Siba PN
Alternate External
Ferraz-Shawmut PN
[kW]/[HP] Type JFHR2 Type JFHR2
132/200 170M3017 2061032.315 6.9URD30D08A0315
160/250 170M3018 2061032.35 6.9URD30D08A0350
200/300 170M4011 2061032.35 6.9URD30D08A0350
250/350 170M4012 2061032.4 6.9URD30D08A0400
315/450 170M4014 2061032.5 6.9URD30D08A0500
400/550 170M5011 2062032.55 6.9URD32D08A0550
450/600 170M4017
500/650 170M4017 20 610 32.700 6.9URD31D08A0700
560/750 170M6013 20 610 32.700 6.9URD31D08A0700
630/900 170M6013 22 610 32.900 6.9URD33D08A0900
710/1000 170M7081 22 610 32.900 6.9URD33D08A0900
800/1150 170M7081
900/1250 170M7081
1000/1350 170M7081
1200/1600 170M7082
1400/1900 170M7083
Table 12.23 525–690 V, above 125 HP
AF-600 Bussmann PN Rating Alternate Siba PN
[kW]/[HP]
710/1000 170M8611 1100 A, 1000 V 20 781 32.1000
800/1150 170M8611 1100 A, 1000 V 20 781 32.1000
900/1250 170M8611 1100 A, 1000 V 20 781 32.1000
1000/1350 170M8611 1100 A, 1000 V 20 781 32.1000
1200/1600 170M8611 1100 A, 1000 V 20 781 32.1000
1400/1900 170M8611 1100 A, 1000 V 20 781 32.1000
Table 12.24 525–690 V, Frame Size 6, Inverter Module DC Link Fuses
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for external use
**Any minimum 500 V UL-listed fuse with associated current rating may be used to meet UL requirements.
Specifications AF-600 FP Design and Installation Guide
DET-768A 12-25
