GE af-600 fp

Figure 1.7 Inverter Cabinet, Unit Sizes 62 and 64
(Unit Sizes 61 and 63 are similar with two inverter modules)
1) External Temperature Monitoring 6) Motor
2) AUX Relay U V W
01 02 03 96 97 98
04 05 06 T1 T2 T3
4) AUX Fan 8) Fan Fuses. See 12.3 Fuse Tables for part numbers
100 101 102 103 9) SMPS Fuses. See 12.3 Fuse Tables for part numbers
L1 L2 L1 L2
Table 1.6
Introduction AF-600 FP Design and Installation Guide
DET-768A 1-7
1 1
