2 Preinstallation instructions
10 GE Healthcare 32551-IMG rev 6
2.2 STRENGTH/DURABILITY REQUIREMENTS FOR THE
WALL AND FLOOR
If the device is mounted on a wall, the pulling force exerted on each bolt is
approximately 600 N (135 lbs). The load on the floor is approximately 7350
kg/sq.m (1500 lb/sq.ft).
If the device is mounted on a base plate, the load on the floor is
approximately 600 kg/sq.m (122 lb/sq.ft).
2.3 ELECTRICAL SUPPLY REQUIREMENTS
NOTE!
Operating Range 198 to 242VAC. Line voltages measuring less than 208
VAC may require a line boost transformer.
Line Voltage
220 VAC (nominal)
(tap selection 220, 240 or 260 VAC)
Line Regulation
± 2% (full load)
Phase
single phase (Line, Neutral,
Protective Ground or L1, L2,
Protective Ground)
Frequency
50/60Hz
Current
stand-by 1A
maximum 20 A
instantaneous peak 30 A
Branch Circuit: dedicated Line,
Neutral, Protective Ground 2.5mm2
(L1 and L2 10 AWG, stranded wire,
continuous run)
circuit breaker 20 A, 2-pole
(outlet per local code requirements
or NEMA 6-20)
VDE Wall plug is included
Grounding
dedicated, wired (not conduit)
0-potential (earth) ground
Standard outlet
(220/120V/15A) required for any
optional accessories
