2 Preinstallation instructions
12 GE Healthcare 32551-IMG rev 6
2.7 TEST EQUIPMENT NEEDED FOR INSTALLATION
– Digital True RMS Multimeter
– Oscilloscope
– Compression force gauge (bathroom scale)
– Densitometer
– Acrylic blocks 2x10mm, 2x20mm
– Sensitometer
– Lux-meter
– 0.1mm Al plates (in USA)
– Radiation meter for mammo to measure dose
– kV meter for mammo (Unfors, RTI, PMX-I/M or equivalent)
2.8 TRANSPORTATION OF AN ASSEMBLED UNIT
The C-arm has to be removed if the mammography system is transported
in a car or longer distances.
The carriage of the unit does not tolerate additional stress from such
transportation.
2.9 UNPACKING THE UNIT
The standard unit delivery comprises three (four in base plate installation)
crates (check that they have the same serial number) of the following
dimensions and with these contents:
NOTE!
The crate numbers in the packing list may differ from the numbers listed
here.
Crate 1:
– 2290 x 520 x 410 mm (90 3/16” x 20 1/2” x 16 3/16”)
– cardboard
– gross weight approximately 89 kg (196 lb)
– Alpha stand and column assembly
Crate 2:
– 1190 x 550 x 710 mm (46 7/8” x 21 5/8” x 28”)
– cardboard
– gross weight approximately 52 kg (115 lb)
– C-arm assembly
Crate 3:
– 1150 x 230 x 200 mm (45 5/16” x 9” x 7 7/8”)
–wooden
– gross weight: without ECS approximately 92 kg (203 lb), with ECS
approximately 104 kg (230 lb)
– counterweight (with or without additional counterweight for ECS)
