2 Preinstallation instructions
32551-IMG rev 6 GE Healthcare 11
2.4 ENVIRONMENTAL REQUIREMENTS
NOTE!
Long term storing in dry cool place.
2.5 INSTALLATIONS REQUIREMENTS & ENVIRONMENT
CONTROL
In order to minimize interference risks, the following requirements shall
apply.
Cables shielding & grounding
All interconnect cables to peripheral devices must be shielded and
properly grounded. Use of cables not properly shielded and grounded
may result in the equipment causing radio frequency interference.
Stacked components & equipment
The Alpha RT should not be used adjacent to or stacked with other
equipment; if adjacent or stacked use is necessary, the Alpha RT should be
observed to verify normal operation in the configuration in which it will be
used.
Electrostatic discharges environment & recommendations
In order to reduce electrostatic discharges interferences, the floor
material shall be a dissipative material, versus the electrostatic charge
stacking. The relative humidity shall be at least 30 percent. The dissipative
material shall be connected to the system ground reference.
Pins of connectors should not be touched and connections should not be
made to these connectors unless ESD precautionary procedures are used.
2.6 TOOLS NEEDED FOR INSTALLATION
– Electrical screwdriver (to open the crates)
– Screwdrivers small/medium
– Screwdrivers POZIDRIVE small/medium
– Allen key set (long type 1.5 - 8 mm)
– Wrench set 7 - 19 mm.
–Pliers
– Drilling machine with 10 mm bit for wall mounting
Operating Temperature
+10...+40°C (60° - 85°F)
Humidity Range
15 - 85%, non-condensing
Weight
258 kg (568 lbs)
Dimensions
Height 224 cm (88.2”)
Width 34.2 cm (13.5”)
Length 101.5 cm (40”)
