Revision D 170 Series Monitor 4-5
2003023-001
Setup Procedures: Loading Strip Chart Paper
6. Unfold two sheets from the top of the pack so that they extend toward you.
Figure 4-5. Creating a Paper Leader
7. Place the pack in the drawer so that the pack is laying flat in the bottom of the
paper tray.
Figure 4-6. Inserting the Paper
