APPENDIX A: DEFAULT ROLE-BASED ACCESS CONTROL MODEL
D20MX INSTRUCTION MANUAL GE INFORMATION 107
Table 54: Modify access flags for DNP V1.00 Data Link (Application number: 17)
Table 55: Read access flags for DNP V1.0 Data Link (Application number: 17)
Table 56: Modify access flags for Quantum Meter Scanner DCA (Application number: 18)
Table 57: Read access flags for Quantum Meter Scanner DCA (Application number: 18)
Table 58: Modify access flags for CDC Type 1 DPA (Application number: 23)
Table 59: Read access flags for CDC Type 1 DPA (Application number: 23)
Bit
Position
Description Administrator
(2)
Engineer
(1)
Operator
(3)
Observer
(0)
0 Update counters in the DNP Comm.
Statistics Display
Yes Yes Yes No
1 - 31 Not Used Yes Yes Yes No
Bit
Position
Description Administrator
(2)
Engineer
(1)
Operator
(3)
Observer
(0)
0 DNP Comm. Statistics Display Yes Yes Yes Yes
1 - 31 Not Used Yes Yes Yes No
Bit
Position
Description Administrator
(2)
Engineer
(1)
Operator
(3)
Observer
(0)
0 - 1 Not Used Yes Yes Yes No
2 Update counters in Quantum Meter
Status Display
Yes Yes Yes No
1 - 31 Not Used Yes Yes Yes No
Bit
Position
Description Administrator
(2)
Engineer
(1)
Operator
(3)
Observer
(0)
0 Quantum Function Menu Yes Yes Yes Yes
1 Quantum Meter Data Display Yes Yes Yes Yes
2 Quantum Meter Status Display Yes Yes Yes Yes
3 - 31 Not Used Yes Yes Yes No
Bit
Position
Description Administrator
(2)
Engineer
(1)
Operator
(3)
Observer
(0)
0 - 31 Not Used Yes Yes Yes No
Bit
Position
Description Administrator
(2)
Engineer
(1)
Operator
(3)
Observer
(0)
0 Main Menu Yes Yes Yes No
1 - 8 Not Used Yes Yes Yes No
9 Accumulators Display,
Analog Inputs Display,
Direct Analog Outputs Display,
SBO Analog Outputs Display,
Direct Controls Display,
SBO Controls Display,
Status Inputs Display,
Direct Setpoints Display, and
SBO Setpoints Display
Yes Yes Yes No
10 - 31 Not Used Yes Yes Yes No
