56 GE INFORMATION D20MX INSTRUCTION MANUAL
CHAPTER 4: POWERING-UP AND TESTING
Accessing WESMAINT II+ using a terminal
You can use a VT100-compatible terminal or a terminal emulation program to directly
access the WESMAINT II+ facility. SGConfig's Terminal Emulator is an example of a suitable
terminal emulation program.
For further information about using WESMAINT II+ software to perform any of the test
procedures in this section, refer to the WESMAINT II+ User’s Guide.
Terminal Emulation
Microsoft Windows™ HyperTerminal can be used for terminal emulation but it is NOT
recommended because code and configuration file download times are considerably
increased.
The program Tera Term for Microsoft Windows™ does not have these limitations and is
therefore recommended as a terminal emulation program. It can be downloaded from the
Internet.
SHELL
The SHELL is a debugging and diagnostics tool that is accessible as a menu selection in
WESMAINT II+, or from a basic login prompt if WESMAINT II+ is not available.
The approved method of using the diagnostic tools of the SHELL is through the front RS232
port.
Power up and test steps
To power up and test the D20MX:
1. “Set up a PC to act as a WESMAINTII+ terminal”. See page 57.
2. “Power up the D20MX” on page 57. See page 57.
Result: The D20MX automatically runs the Online Start-up test. See “Automatic on-line
start-up test” on page 57.
3. “Test for redundancy”. See page 58.
4. “Check that fail-over is functioning correctly”. See page 59.
5. “Check that switch-over is functioning correctly”. See page 59.
6. “Verify either hardware or software switch-over”. See page 60.
