140 GE INFORMATION D20MX INSTRUCTION MANUAL

APPENDIX D: USING CONFIGPRO WITH D20MX

Application definition files and default

configurations

The D20MX Documentation CD or extracted zip file contains numerous folders and files.

The three main folders for the purpose of this document are highlighted below.

The D20MX Documentation CD or extracted zip file contains all of the following:

• Configuration guides, including the Wesmaint II+ user and configuration guides.

• Factory Default Configuration files: Application Definitions/D20MXv1_3Appldefs. The

ConfigPro sub-folder contains the factory default zipped ConfigPro files.

Staging factory default configuration files

To stage the factory default configuration files so that they may be accessed by ConfigPro:

1. Press the Windows Key and E at the same time.

Result: The Windows Explorer window appears.

2. Navigate to a folder to which you have write permissions.

Result: The content of the folder appears.

3. Click the New folder button in Windows Explorer

Result: A new folder is created with the name “New folder” and the cursor is positioned

to allow renaming of the folder.

4. Rename the folder to D20MXV13X.

Result: The folder is renamed to D20MXV13X.

5. Access the D20MX Documentation CD files by either:

5.1. Insert the D20MX Documentation CD in to the computer’s DVD/CD drive, or

5.2. Extract the D20MX Documentation CD zip file on to the root of your C: drive and

double click the readme.html file under the ISO-Image sub-folder, which is

nested two levels deep into the extracted folder.

Result: The Documentation CD home page appears in your default Web Browser.

Result: Alternately for step 5.1, the home page does not appear in your default Web

Browser. In this case, navigate to the CD in Windows Explorer, and double-click the

readme.html file on the root of the CD.
