CHAPTER 5: CONFIGURING THE SOFTWARE
4.3. Click OK.
Result: Tera Term main window appears and is communicating at 115,200
baud.
5. Download the application image file:
5.1. Press Enter to verify that communication is active.
Result: The D20M> prompt appears if the connection is active.
5.2. Type rz and press Enter to put the D20MX into the state where it is ready to
receive the downloadable code file
5.3. Click File > Transfer > ZMODEM > Send from menu bar
Result: A dialog box opens, prompting you to locate the appl.out file that you
wish to download.
5.4. Select the correct file, and click Open to start the transfer
NOTE
Do not press any keys on keyboard and do not move the Tera Term window
during download.
Result: The file transfer may take from less than 10 to over 30 minutes,
depending on communication speed selected.
When complete, the D20M> prompt appears.
6. Download the operating system image file
6.1. Press Enter to verify that communication is active.
Result: The D20M> prompt returns if connection is active
6.2. Type rz and press Enter to put the D20MX into the state where it is ready to
receive the downloadable code file.
6.3. Click File > ZMODEM > Send from menu bar.
Result: A dialog box appears, prompting you to locate the vxWorks file that you
wish to download.
6.4. Select the correct file, and click Open to start the transfer
NOTE
Do not press any keys on keyboard and do not move the Tera Term window
during download.
Result: The file transfer may take from less than 10 to over 30 minutes,
depending on communication speed selected.
When complete, the D20M> prompt appears.
7. Type al 0 to ensure the autologout timer does not interrupt the copy to flash.
8. Type cf to copy the image files to flash.
Result: The copy may take a few minutes to complete. When complete, the D20M>
prompt appears.
9. Type el /r to ensure that log is clear.
10. Type boot to restart device.
Result: The image file load is completed.
The flash memory of the D20MX now has the new application and operating system
image file loaded.
Configuration File
Download
You can use standard SGConfig procedures to download a configuration file over the serial
port.
Download image files over a network connection
Procedure To download application and operating system image files to the D20MX over a network
connection:
