D20MX INSTRUCTION MANUAL GE INFORMATION 109
D20MX Processor
Appendix B: Standards & Protection
Standards & Prote ction
This Appendix lists the standards with which the D20MX has been tested for compliance.
Compliance standards
Compliance standards are listed for the following categories:
• Emission standards; see Table 68
• Immunity standards; see Table 69
• Safety publications; see Table 70
• Environmental standards; see Table 71
Table 68: Emission standards
Table 69: Immunity standards
Standard Name Description Test Specification
EN55011 (CISPR 11)
1
ISM RF equipment – Electromagnetic
disturbance characteristics
Radiated Emissions 30 MHz to
1
GHz
Conducted Emissions 150 kHz –
30
MHz
Standard Name Description Test Specification
IEC 61000-4-2 Electrostatic discharge (ESD) immunity
test
Contact Discharge: 8 kV
Air Discharge: 15 kV
HCP and VCP: 8 kV
IEC 61000-4-3
IEC 61850-3: clause 5.7.2
Radiated, radio-frequency
electromagnetic field immunity test
80 MHz to 1 GHz: 10V/m
1.4 GHz to 2 GHz: 3V/m
2 GHz to 3 GHz: 1V/m
IEC 61000-4-4
IEC 61850-3: clause 5.7.1.4
Electrical fast transient/burst immunity
test
Direct Couple: 4 kV/5 kHz
Capacitive Clamp: 2 kV/
5
kHz
IEC 61000-4-5 Surge immunity test
