CHAPTER 1: BEFORE YOU START
D20MX INSTRUCTION MANUAL GE INFORMATION 17
D20MX applications
Table 2 lists the applications included in the D20MX firmware.
NOTE
* An Application ID containing an “N” (e.g., A009N) signifies a unique application definition
for the D20MX.
† The D20MX version of the application is based on this D20 classic application version.
However, the D20MX version is not identical to the D20 classic version due to minor
changes to improve the robustness and security of the original application.
‡ The version of B009 in SAN0002 is actually based on D20 classic application version 401
but modified to be compatible with the version 310 application definition version.
Ф The version of B021 in SAN002 is actually based on D20 classic application version 991
but modified to be compatible with the version 912 application definition version.
Table 2: D20MX applications
License
Group
D20MX
Application ID
Base D20 Classic
Application Version †
Application Name Description
Common Application Definitions
001 A009N 805 PG&E DPA for D20MX Pacific Gas and Electric (PG&E) data-processing
application (DPA) for remote terminal units
(RTUs).
001 A017N 131 Distributed Network
Protocol V1.00 DCA for
D20MX
Distributed Network
Protocol (DNP) V1.0 Data Link Application.
Required by the Quantum Meter Scanner DCA.
001 A018 120 Quantum Meter Scanner
DCA
The Quantum Meter Scanner DCA obtains data
from one or more Quantum Meters via the DNP
interface.
001 A023N 423 CDC Type I DPA for D20MX The CDC Type I DPA emulates a CDC Type I RTU
A026-1 321 Communication
Watchdog DTA
Reports on the state of communications
between the RTU and a remote device (Data
Translation Application).
A027N 832 SOE Logger DTA for D20MX The Sequence-of-Events Logger DTA processes
sequence of events (SOEs) from any sub-set of
the system digital input and/or analog input
points.
A030 300 Accumulator Freeze DTA Detects system status point changes and
system accumulator point freezes.
001 A033-5N 211 TEJAS V DPA for D20MX Emulates a remote terminal unit utilizing the
(Valmet/Metso/Telvent) TEJAS V
communication protocol.
A035 211 Analog Reference DTA Monitors analog input points and provides the
system database with pseudo analog values
that represent either correctly functioning
analog input hardware (good reference value),
or failed analog input hardware (bad reference
value).
001 A036N 421 ProLogic Executor DTA for
D20MX
Provides user programmable soft logic
automation functionality.
001 A041-1 116 Proportional Integral
Der ivative Contro l DTA
The Proportional, Integral and Derivative (PID)
DTA uses the generally-accepted industry
standard for control of closed loop processes.
A048 210 Status Combination DTA Provides one ore more DI points, each of which
provides an event-driven logical OR of a set of
mapped system DI points.
A059-0N 911 Modbus DCA for D20MX Acts as a data concentrator for one or more
Sub-Remote Units (SRUs) using the MODBUS
communication protocol (RTU & ASCII modes).
