28 GE INFORMATION D20MX INSTRUCTION MANUAL

CHAPTER 1: BEFORE YOU START

Table 10 lists the parts provided in each D20MX upgrade kit.

Table 10: Upgrade kit parts

Table 11 lists the parts provided in each D20MX spare kit.

Table 11: Spare kit parts

Part Number Part Description

D20MXK-AAUXXUUU

D20MXK-ACUXXUUU

D20MXK-AGEXXUUU

D20MXK-AGFXXUUU

526-3001 D20MX CPU non VME 2x10/100/1000 BaseTX 1

526-3003 D20MX CPU non VME 2x100 BaseFX (Front Access) 1

526-3005 D20MX CPU non VME 2x100 BaseFX (Rear Access) 1 1

526-3103LF D20MX 100Base-FX Rear LC FO Card 1

526-3104LF D20MX 100Base-FX Rear ST FO Card 1

975-1236 D20MX CPU to D20MX Rear FO Card Harness 1 1

975-1237 Termination panel to Backplane 0 V Harness 1 1 1 1

953-1014 Blank Plate for D20MX Install 1 1 1 1

953-1015 Lower filler cover plate 1 1 1 1

581-0002 GE Digital Energy Products Documentation CD 1 1 1 1

588-0075 V14X GE Digital Energy D20MX Documentation CD 1 1 1 1

977-0529/72 Cable, Null Modem DB9F-DB9F, 80 °C, 150 V 1 1 1 1

460-0073 Ferrite clamp 1 1 1 1

Part Number Part Description

D20MXK-CAUXXUUU

D20MXK-CCUXXUUU

D20MXK-CGEXXUUU

D20MXK-CGFXXUUU

526-3001 D20MX CPU non VME 2x10/100/1000 BaseTX 1

526-3003 D20MX CPU non VME 2x100 BaseFX (Front Access) 1

526-3005 D20MX CPU non VME 2x100 BaseFX (Rear Access) 1 1

526-3103LF D20MX 100Base-FX Rear LC FO Card 1

526-3104LF D20MX 100Base-FX Rear ST FO Card 1
