Programming Site Data 1-3
March 2008
Table 1-1: Model DF868 Key Functions
Key Unshifted Function Shifted Function
Software Function Keys - press to
select the functions displayed directly
above them in the option bar. These
keys apply only to the left pane of the
display screen.
None
Software Function Keys - press to
select the functions displayed directly
above them in the option bar. These
keys apply only to the right pane of the
display screen.
None
Shift Key - use this red key to access
the shifted function of the other keys.
One press shifts the next keystroke
only, while two presses locks the key-
pad in shifted mode. A third press
releases the shift function.
None
Arrow Keys - in measurement mode,
use to scroll through function choices
on the option bar. In programming
mode, use to scroll through menu
choices. The [←] also acts as a back-
space key in programming mode.
Use to enter the letters A, B, C and
D, respectively.
Program Key - press to enter the User
Program. See page 1-8 for details.
Use to enter the letter Q.
