March 2008
4-4 Printing Data
Numeric Format (cont.) Refer to Chapter 3, Diagnostics, of the Service Manual for a
discussion of the many parameters accessible via the
DIAG option.
Note: The units assigned to the parameters in Table 4-2 on page 4-3
are those selected in the User Program (
SYSTM submenu).
5. Use the [←], [→] and
[F1]-[F4] keys to select the second parameter
to be printed. See Table 4-2 on page 4-3 for a list of the available
options.
6. Use the [←], [→] and
[F1]-[F4] keys to select the third parameter to
be printed. See Table 4-2 on page 4-3 for a list of the available
options.
7. Use the [←], [→] and
[F1]-[F4] keys to select the desired Time
Increment (the frequency at which measurements are taken). The
available options at this prompt are: 5sec, 10sec, 30sec, 1min,
3min, 6min and 12min.
After the time increment is chosen, the Model DF868 returns to the
standard data display screen and continues to take measurements. The
live data is printed at the specified time intervals, until a
STOP
command is issued (see the instructions for the
STOP submenu on
page 4-9). A portion of a typical printout is shown in Figure 4-1
below.
Figure 4-1: A Typical Numeric Printout
DATA_DUMP OF (SITE NAME)
Channel LABEL Channel MESSAGE
Start Date
Start Time
HH:MM:SS
03:08:40
03:08:50
03:09:00
03:09:10
03:09:20
03:09:30
03:09:40
03:09:50
03:10:00
03:10:10
.
.
.
ACF/HR
686.85
684.00
678.12
680.58
.
.
670.70
675.99
669.79
675.59
662.28
666.71
.
VOLUM
232.57
236.34
234.46
.
.
.
ACF
230.45
228.58
226.71
224.84
222.70
220.83
218.92
+TOTL
20 OCT 97
03:08:40 PM
1039.082
.
.
1038.860
1039.255
.
FT/S
1039.511
1039.105
1039.137
1039.470
1039.509
1039.003
1039.147
SNDSP
CH1 CH1 CH1
