96
K0320 Issue No. 1
To start/stop a ‘one shot’ ramp
Press to start a one shot ramp for
signal increase and press
to start
this ramp for signal decrease.
Press
and simultaneously to
‘freeze’ the ramp action.
To restart press
or . Press CE to
cancel the ramping operation.
To start/stop ramp cycling
Press
and direct after each other
to start a continuous up and down
ramp cycling with dwelling at the high
and low ends. The first arrow key hit
determines the take-off direction.
Press
and simultaneously to
‘freeze’ the ramp action. To restart
press
or . Press CE to cancel the
ramping operation.
Scaled readings
Dial directly in scaled readings to SET
a related output signal as set-up.
Press EXE to actually output the signal.
The and key functions are
available to fine adjust the output.
Special Output Functions
