Page Value Text Displayed Description
1 PAGE 3: ACTUAL VALUES
MOTOR CAPACITY DATA
Page header
2 ESTIMATED TIME TO
TRIP = xxx SECONDS
3 3 MOTOR LOAD AS A PERCENT
FULL LOAD = xxx PERCENT
4 THERMAL CAPACITY
USED = xxx PERCENT
5 END OF PAGE THREE:
ACTUAL VALUES
Page footer
1 PAGE 4: ACTUAL VALUES
STATISTICAL DATA
Page header
2 RUNNING HOURS SINCE LAST
COMMISSIONING xxx HOURS
3 MEGAWATTHOURS SINCE LAST
COMMISSIONING xxx MWHR
Displayed only if MTM unit is installed in 269
4 # OF STARTS SINCE LAST
COMMISSIONING xxx
5 # OF TRIPS SINCE LAST
COMMISSIONING xxx
6 # O/L TRIPS SINCE LAST
COMMISSIONING xxx
Overload trips
7 # RAPID TRIPS SINCE LAST
COMMISSIONING xxx
8 # U/B TRIPS SINCE LAST
COMMISSIONING xxx
Unbalance trips
4 9 # G/F TRIPS SINCE LAST
COMMISSIONING xxx
Ground-fault trips
10 # RTD TRIPS SINCE LAST
COMMISSIONING xxx
11 # S/C TRIPS SINCE LAST
COMMISSIONING xxx
Short-circuit trips
12 # START TRIPS SINCE LAST
COMMISSIONING xxx
13 # U/V TRIPS SINCE LAST
COMMISSIONING xxx
Undervoltage trips
14 # O/V TRIPS SINCE LAST
COMMISSIONING xxx
Overvoltage trips
15 # PF TRIPS SINCE LAST
COMMISSIONING xxx
Power-failure trips
16 VOLTAGE PHASE REVERSALS
SINCE COMMISSIONING xxx
17 START NEW COMMISSIONING
NO
Press STORE to start; message changes to
YES
4 18 END OF PAGE FOUR:
ACTUAL VALUES
Page footer
1 PAGE 5: ACTUAL VALUES
PRE-TRIP DATA
Page header
