90 PMCS Interface Toolkit
Page Value Text Displayed Description
2 CAUSE OF LAST TRIP
message
Message is a brief explanation of trip cause
3 PRE-TRIP AVERAGE MOTOR
CURRENT = xxx AMPS
4 PRE-TRIP U/B RATIO
(lI/Ip) xxx PERCENT
Unbalance
5 PRE-TRIP G/F CURRENT
G/F=xxx.0 AMPS
Units = *.1 if G/F CT
ratio = 2000:1
56 PRE-TRIP MAX STATOR RTD
RTD #XX = xxx C
7 PRE-TRIP AVERAGE VOLTAGE
VOLTS = xxx
Displayed only if MTM unit is installed in 269
8 PRE-TRIP KWATTS
KW = xxx
Displayed only if MTM unit is installed in 269
9 PRE-TRIP KVARS
KVAR = xxx
Displayed only if MTM unit is installed in 269
10 PRE-TRIP POWER FACTOR
PF = xxx
Displayed only if MTM unit is installed in 269
11 PRE-TRIP FREQUENCY
HZ = xxx
Displayed only if MTM unit is installed in 269
12 END OF PAGE FIVE
ACTUAL VALUES
Page footer
1 PAGE 6: ACTUAL VALUES
LEARNED PARAMETERS
Page header
2 LEARNED Istart (AVG OF 4
STARTS)=xxx AMPS
3 LEARNED Istart (last one)
=xxx AMPS
4 LEARNED K FACTOR
K = xxx AMPS
6 5 LEARNED RUNNING COOL
TIME-xxx MIN
6 LEARNED STOPPED COOL
TIME = xxx MIN
7 LEARNED ACCEL TIME
ACCEL TIME = xxx SEC
8 LEARNED Start Capacity
Required = xxx PERCENT
9 END OF PAGE SIX
ACTUAL VALUES
Page footer
1 PAGE 7: ACTUAL VALUES
METERING DATA
Page header
2 Vab = xxx Vbc = xxx
Vac = xxx (VOLTS)
or
MTM METER MODULE
NOT INSTALLED
Displayed only if MTM unit is on line
3 3 PHASE KWATTS
KW = xxx
Displayed only if MTM unit is on line
