GE F60 - Monitoring Elements

GE Multilin F60 Feeder Protection System 5-257
5 SETTINGS 5.7 CONTROL ELEMENTS
5
5.7.12 MONITORING ELEMENTS
a) MAIN MENU
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS
b) HIGH IMPEDANCE FAULT DETECTION
PATH: SETTINGS  CONTROL ELEMENTS  MONITORING ELEMENTS  HI-Z
 MONITORING
 ELEMENTS
 HI-Z

See page 5–257.
MESSAGE
 BREAKER 1
 ARCING CURRENT
See page 5–264.
MESSAGE
 BREAKER 2
 ARCING CURRENT
See page 5–264.
MESSAGE
 BREAKER
 FLASHOVER 1
See page 5–267.
MESSAGE
 BREAKER
 FLASHOVER 2
See page 5–267.
MESSAGE
 BREAKER RESTRIKE 1

See page 5–272.
MESSAGE
 INCIPIENT FAULT 1

See page 5–275.
MESSAGE
 INCIPIENT FAULT 2

See page 5–275.
MESSAGE
 VT FUSE FAILURE 1

See page 5–277.
MESSAGE
 VT FUSE FAILURE 2

See page 5–277.
MESSAGE
 VT FUSE FAILURE 3

See page 5–277.
MESSAGE
 VT FUSE FAILURE 4

See page 5–277.
MESSAGE
 BROKEN CONDUCTOR 1

See page 5–279.
MESSAGE
 BROKEN CONDUCTOR 2

See page 5–279.
MESSAGE
 BROKEN CONDUCTOR 3

See page 5–279.
MESSAGE
 BROKEN CONDUCTOR 4

See page 5–279.
MESSAGE
 THERMAL OVERLOAD
 PROTECTION
See page 5–281.
 HI-Z

HI-Z FUNCTION:
Disabled
Range: Disabled, Enabled
MESSAGE
HI-Z SOURCE:
SRC 1
Range: SRC 1, SRC 2, SRC 3, SRC 4
