6.2 STATUS 6 ACTUAL VALUES
6
The AVERAGE MSG RETURN TIME is the time taken for direct output messages to return to the sender in a direct input/output
ring configuration (this value is not applicable for non-ring configurations). This is a rolling average calculated for the last
ten messages. There are two return times for dual-channel communications modules.
The UNRETURNED MSG COUNT values (one per communications channel) count the direct output messages that do not
make the trip around the communications ring. The CRC FAIL COUNT values (one per communications channel) count the
direct output messages that have been received but fail the CRC check. High values for either of these counts may indicate
on a problem with wiring, the communication channel, or one or more relays. The
UNRETURNED MSG COUNT and CRC FAIL
COUNT values can be cleared using the CLEAR DIRECT I/O COUNTERS command.
The
DIRECT INPUT 1 to DIRECT INPUT (32) values represent the state of each direct input.
6.2.17 DIRECT DEVICES STATUS
PATH: ACTUAL VALUES  STATUS  DIRECT DEVICES STATUS
These actual values represent the state of direct devices 1 through 16.
6.2.18 IEC 61850 GOOSE INTEGERS
PATH: ACTUAL VALUES  STATUS  IEC 61850 GOOSE UINTEGERS
The F60 Feeder Protection System is provided with optional IEC 61850 communications capability. This
feature is specified as a software option at the time of ordering. See the Order Codes section in chapter 2
for details.
The IEC 61850 GGIO5 integer input data points are displayed in this menu. The GGIO5 integer data values are received
via IEC 61850 GOOSE messages sent from other devices.
6.2.19 EGD PROTOCOL STATUS
a) FAST EXCHANGE
PATH: ACTUAL VALUES  STATUS  EGD PROTOCOL STATUS  PRODUCER STATUS  FAST EXCHANGE 1
 DIRECT DEVICES
 STATUS
DIRECT DEVICE 1
STATUS: Offline
Range: Offline, Online
MESSAGE
DIRECT DEVICE 2
STATUS: Offline
Range: Offline, Online
↓
MESSAGE
DIRECT DEVICE 16
STATUS: Offline
Range: Offline, Online
 IEC 61850
 GOOSE UINTEGERS
UINT INPUT 1
0
MESSAGE
UINT INPUT 2
0
↓
MESSAGE
UINT INPUT 16
0
 FAST EXCHANGE 1

FAST EXCHANGE 1
SIGNATURE: 0
