Accuracy is the estimated maximum time error at present in the RTC, considering the quality information imbedded in the
received time signal. The value 999,999,999 indicates that the magnitude of the estimated error is one second or more, or
that the error cannot be estimated.
PORT 1…3 PTP STATE is the present state of the port’s PTP clock. The PTP clock state is:
• DISABLED is the port’s function setting is Disabled,
•
NO SIGNAL if enabled but no signal from an active master has been found and selected,
• CALIBRATING if an active master has been selected but lock is not at present established,
• SYNCH’D (NO PDELAY) if the port is synchronized, but the peer delay mechanism is non-operational, and
• SYNCHRONIZED if synchronized.
PTP-— IRIG-B DELTA is the time difference, measured in nanoseconds, between the fractional seconds portion of the time
being received via PTP and that being received via IRIG-B. A positive value indicates that PTP time is fast compared to
IRIG-B time.
6.2.15 HI-Z STATUS
PATH: ACTUAL VALUES  STATUS  HIZ STATUS
The current status of high-impedance fault detection element is displayed here. Refer to Theory of operation for information
on element status determination. The arc fault detection confidence is also displayed.
6.2.16 DIRECT INPUTS
PATH: ACTUAL VALUES  STATUS  DIRECT INPUTS
 HIZ STATUS

HIZ STATUS:
NORMAL
Range: Normal, Coordination Timeout, Armed, Arcing,
Down Conductor
MESSAGE
ARC CONFIDENCE A:100
B:100 C:100 N:100 %
 DIRECT INPUTS

AVG MSG RETURN
TIME CH1: 0 ms
MESSAGE
UNRETURNED MSG
COUNT CH1: 0
MESSAGE
CRC FAIL COUNT
CH1: 0
MESSAGE
AVG MSG RETURN
TIME CH2: 0 ms
MESSAGE
UNRETURNED MSG
COUNT CH2: 0
MESSAGE
CRC FAIL COUNT
CH2: 0
MESSAGE
DIRECT INPUT 1:
On
MESSAGE
DIRECT INPUT 2:
On
↓
MESSAGE
DIRECT INPUT 32:
On
