GE Multilin F60 Feeder Protection System 6-31
6 ACTUAL VALUES 6.4 RECORDS
6
6.4.7 HI-Z RECORDS
PATH: ACTUAL VALUES  RECORDS  HIZ RECORDS
Two types of high impedance fault detection element records are stored in non-volatile memory and available from this
menu. If the element is triggered by a high impedance overcurrent condition, then the records are displayed in the
RMS 1 to
RMS 4 actual values. If the element is triggered by high impedance fault detection arcing algorithm, then the records are dis-
played in the HIZ 1 to HIZ 4 actual values. Refer to High impedance fault detection section in chapter 5 for more information.
 HIZ RECORDS

FORCE TRIGGER:
No
MESSAGE
HIZ 1:NONE
1970/01/01 00:00:00
MESSAGE
HIZ 2:NONE
1970/01/01 00:00:00
MESSAGE
HIZ 3:NONE
1970/01/01 00:00:00
MESSAGE
HIZ 4:NONE
1970/01/01 00:00:00
MESSAGE
RMS 1:NONE
1970/01/01 00:00:00
MESSAGE
RMS 2:NONE
1970/01/01 00:00:00
MESSAGE
RMS 3:NONE
1970/01/01 00:00:00
MESSAGE
RMS 4:NONE
1970/01/01 00:00:00
