GE Multilin F60 Feeder Protection System 6-19
6 ACTUAL VALUES 6.3 METERING
6
The metered phase voltage values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see
SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
e) AUXILIARY VOLTAGE METERING
PATH: ACTUAL VALUES  METERING  SOURCE SRC 1  AUXILIARY VOLTAGE
The metered auxiliary voltage values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see
SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
f) POWER METERING
PATH: ACTUAL VALUES  METERING  SOURCE SRC 1  POWER
MESSAGE
SRC 1 PHASOR Vab:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbc:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vca:
0.000 V 0.0°
MESSAGE
SRC 1 ZERO SEQ V0:
0.000 V 0.0°
MESSAGE
SRC 1 POS SEQ V1:
0.000 V 0.0°
MESSAGE
SRC 1 NEG SEQ V2:
0.000 V 0.0°
 AUXILIARY VOLTAGE
 SRC 1
SRC 1 RMS Vx:
0.00 V
MESSAGE
SRC 1 PHASOR Vx:
0.000 V 0.0°
 POWER
 SRC 1
SRC 1 REAL POWER
3φ: 0.000 W
MESSAGE
SRC 1 REAL POWER
φa: 0.000 W
MESSAGE
SRC 1 REAL POWER
φb: 0.000 W
MESSAGE
SRC 1 REAL POWER
φc: 0.000 W
MESSAGE
SRC 1 REACTIVE PWR
3φ: 0.000 var
MESSAGE
SRC 1 REACTIVE PWR
φa: 0.000 var
MESSAGE
SRC 1 REACTIVE PWR
φb: 0.000 var
MESSAGE
SRC 1 REACTIVE PWR
φc: 0.000 var
MESSAGE
SRC 1 APPARENT PWR
3φ: 0.000 VA
