B-16 F60 Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
16C7 ...Repeated for Field RTD 8
Field Unit Transducer Actuals (Read Only) (8 modules)
16C8 Field Transducer 1 Value -32.768 to 32.767 --- 0.001 F004 0
16CA ...Repeated for Field Transducer 2
16CC ...Repeated for Field Transducer 3
16CE ...Repeated for Field Transducer 4
16D0 ...Repeated for Field Transducer 5
16D2 ...Repeated for Field Transducer 6
16D4 ...Repeated for Field Transducer 7
16D6 ...Repeated for Field Transducer 8
Frequency Rate of Change Actual Values (Read Only) (4 modules)
16E0 Frequency Rate of Change 1 -327.67 to 327.67 Hz/s 0.01 F002 0
16E1 Reserved (3 items) 0 to 65535 --- 1 F001 0
16E4 ...Repeated for Frequency Rate of Change 2
16E8 ...Repeated for Frequency Rate of Change 3
16EC ...Repeated for Frequency Rate of Change 4
Source Current (Read Only) (4 modules)
1800 Source 1 Phase A Current RMS 0 to 999999.999 A 0.001 F060 0
1802 Source 1 Phase B Current RMS 0 to 999999.999 A 0.001 F060 0
1804 Source 1 Phase C Current RMS 0 to 999999.999 A 0.001 F060 0
1806 Source 1 Neutral Current RMS 0 to 999999.999 A 0.001 F060 0
1808 Source 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
180A Source 1 Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
180B Source 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
180D Source 1 Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
180E Source 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
1810 Source 1 Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
1811 Source 1 Neutral Current Magnitude 0 to 999999.999 A 0.001 F060 0
1813 Source 1 Neutral Current Angle -359.9 to 0 degrees 0.1 F002 0
1814 Source 1 Ground Current RMS 0 to 999999.999 A 0.001 F060 0
1816 Source 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
1818 Source 1 Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
1819 Source 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
181B Source 1 Zero Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
181C Source 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
181E Source 1 Positive Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
181F Source 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
1821 Source 1 Negative Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
1822 Source 1 Differential Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
1824 Source 1 Differential Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
1825 Reserved (27 items) --- --- --- F001 0
1840 ...Repeated for Source 2
1880 ...Repeated for Source 3
18C0 ...Repeated for Source 4
Source Voltage (Read Only) (4 modules)
1A00 Source 1 Phase AG Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A02 Source 1 Phase BG Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A04 Source 1 Phase CG Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A06 Source 1 Phase AG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A08 Source 1 Phase AG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A09 Source 1 Phase BG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A0B Source 1 Phase BG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A0C Source 1 Phase CG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A0E Source 1 Phase CG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
Table B–10: MODBUS MEMORY MAP (Sheet 8 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
