B.4 MEMORY MAPPING APPENDIX B
B
3519 RTD Input 42 Value -32768 to 32767 °C 1 F002 0
351A RTD Input 43 Value -32768 to 32767 °C 1 F002 0
351B RTD Input 44 Value -32768 to 32767 °C 1 F002 0
351C RTD Input 45 Value -32768 to 32767 °C 1 F002 0
351D RTD Input 46 Value -32768 to 32767 °C 1 F002 0
351E RTD Input 47 Value -32768 to 32767 °C 1 F002 0
351F RTD Input 48 Value -32768 to 32767 °C 1 F002 0
Ohm Input Values (Read Only) (2 modules)
3520 Ohm Inputs 1 Value 0 to 65535 Ohm 1 F001 0
3521 Ohm Inputs 2 Value 0 to 65535 Ohm 1 F001 0
Expanded Direct Input/Output Status (Read Only)
3560 Direct Device States, one per register (16 items) 0 to 1 --- 1 F155 0 (Offline)
3570 Direct Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
RADIUS Configuration (Read/Write Setting)
3735 Primary RADIUS IP Address 0 to 4294967295 --- 1 F003 0
3737 Primary Authentication Port 1 to 65535 --- 1 F001 1812
3738 Primary Accounting Port 1 to 65535 --- 1 F001 1813
3739 Secondary RADIUS IP Address 0 to 4294967295 --- 1 F003 0
373B Secondary Authentication Port 0 to 65535 --- 1 F001 1812
373D Secondary Accounting Port 0 to 65535 --- 1 F001 1813
373F RADIUS Authentication Method --- --- 1 F619 0 (EAP-TTLS)
3740 RADIUS Vendor ID 1 to 65535 --- 1 F001 2910
3741 Authentication Timeout 0 to 9999 sec 1 F001 10
3742 Authentication Retries 0 to 9999 --- 1 F001 3
3743 RADIUS Authentication Shared Secret --- --- --- F202 (none)
PTP Basic Configuration (Read/Write Setting)
3750 PTP Strict Power Profile 0 to 1 --- 1 F102 0 (Disabled)
3751 PTP Domain Number 0 to 255 --- 1 F001 0
3752 PTP VLAN Priority 0 to 7 --- 1 F001 4
3753 PTP VLAN ID 0 to 4095 --- 1 F001 0
3754 Undefined (2 items) 0 to 1 --- 1 F001 0
PTP Port Configuration (Read/Write Setting) (3 modules)
3756 PTP Port 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3757 PTP Port 1 Path Delay Adder 0 to 60000 ns 1 F001 0
3758 PTP Port 1 Path Delay Asymmetry -1000 to 1000 ns 1 F002 0
3759 ...Repeated for PTP Port 2
375C ...Repeated for PTP Port 3
Real Time Clock Synchronizing Actual Values (Read Only)
375F RTC Sync Source 0 to 5 --- 1 F624 0 (None)
3760 PTP GrandMaster ID 0 to 100 -- 1 F073 0
3764 Real Time Clock Accuracy 0 to 999999999 ns 1 F003 0
3766 PTP Port 1 State (3 items) 0 to 4 -- 1 F625 0 (Disabled)
3769 RTC Offset 0 to 999999999 ns 1 F004 0
376B PTP - IRIG-B Delta -500000000 to 500000000 ns 1 F004 0
Real Time Clock Synchronizing FlexAnalogs (Read Only)
376D PTP - IRIG-B Delta FlexAnalog -262143 to 262143 --- 1 F004 0
Field Units (Read/Write Setting) (8 modules)
3800 Field Unit 1 ID 0 to 1 --- 1 F205 "U1"
3806 Field Unit 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3807 Field Unit 1 Type 0 to 3 --- 1 F243 0 (CC-05)
3808 Field Unit 1 Serial Number 1 to1 --- 1 F205 "000000000000"
380E Field Unit 1 Port 1 to 4 --- 1 F001 1
380F ...Repeated for Field Unit 2
381E ...Repeated for Filed Unit 3
Table B–10: MODBUS MEMORY MAP (Sheet 18 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
