GE Multilin F60 Feeder Protection System B-43
APPENDIX B B.4 MEMORY MAPPING
B
6447 Negative Sequence Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
6448 Negative Sequence Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6449 ...Repeated for Negative Sequence Overvoltage 2
6452 ...Repeated for Negative Sequence Overvoltage 3
Overfrequency (Read/Write Setting) (4 modules)
6470 Overfrequency 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6471 Overfrequency 1 Block 0 to 4294967295 --- 1 F300 0
6473 Overfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
6474 Overfrequency 1 Pickup 20 to 65 Hz 0.01 F001 6050
6475 Overfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 500
6476 Overfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 500
6477 Overfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
6478 Overfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6479 Reserved (4 items) 0 to 1 --- 1 F001 0
647D ...Repeated for Overfrequency 2
648A ...Repeated for Overfrequency 3
6497 ...Repeated for Overfrequency 4
Sensitive Directional Power (Read/Write Grouped Setting) (2 modules)
6680 Sensitive Directional Power 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6681 Sensitive Directional Power 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6682 Sensitive Directional Power 1 RCA 0 to 359 degrees 1 F001 0
6683 Sensitive Directional Power 1 Calibration 0 to 0.95 degrees 0.05 F001 0
6684 Sensitive Directional Power 1 STG1 SMIN -1.2 to 1.2 pu 0.001 F002 100
6685 Sensitive Directional Power 1 STG1 Delay 0 to 600 s 0.01 F001 50
6686 Sensitive Directional Power 1 STG2 SMIN -1.2 to 1.2 pu 0.001 F002 100
6687 Sensitive Directional Power 1 STG2 Delay 0 to 600 s 0.01 F001 2000
6688 Sensitive Directional Power 1 Block 0 to 4294967295 --- 1 F300 0
668A Sensitive Directional Power 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
668B Sensitive Directional Power 1 Events 0 to 1 --- 1 F102 0 (Disabled)
668C Reserved (5 items) 0 to 65535 --- 1 F001 0
6691 ...Repeated for Sensitive Directional Power 2
Load Encroachment (Read/Write Grouped Setting)
66C0 Load Encroachment Function 0 to 1 --- 1 F102 0 (Disabled)
66C1 Load Encroachment Source 0 to 5 --- 1 F167 0 (SRC 1)
66C2 Load Encroachment Minimum Voltage 0 to 3 pu 0.001 F001 250
66C3 Load Encroachment Reach 0.02 to 250 ohms 0.01 F001 100
66C4 Load Encroachment Angle 5 to 50 degrees 1 F001 30
66C5 Load Encroachment Pickup Delay 0 to 65.535 s 0.001 F001 0
66C6 Load Encroachment Reset Delay 0 to 65.535 s 0.001 F001 0
66C7 Load Encroachment Block 0 to 4294967295 --- 1 F300 0
66C9 Load Encroachment Target 0 to 2 --- 1 F109 0 (Self-reset)
66CA Load Encroachment Events 0 to 1 --- 1 F102 0 (Disabled)
66CB Reserved (6 items) 0 to 65535 --- 1 F001 0
Phase Undervoltage (Read/Write Grouped Setting) (3 modules)
7000 Phase Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7001 Phase Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7002 Phase Undervoltage 1 Pickup 0 to 3 pu 0.001 F001 1000
7003 Phase Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite Time)
7004 Phase Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
7005 Phase Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
7006 Phase Undervoltage 1 Block 0 to 4294967295 --- 1 F300 0
7008 Phase Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7009 Phase Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
Table B–10: MODBUS MEMORY MAP (Sheet 35 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
