B-70 F60 Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
CAE3 Direct Input/Output Ch 1 Unreturned Messages Alarm
Events
0 to 1 --- 1 F102 0 (Disabled)
CAE4 Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE8 Direct Input/Output Ch 2 Unreturned Messages Alarm
Function
0 to 1 --- 1 F102 0 (Disabled)
CAE9 Direct Input/Output Ch 2 Unreturned Messages Alarm Msg
Count
100 to 10000 --- 1 F001 600
CAEA Direct Input/Output Ch 2 Unreturned Messages Alarm
Threshold
1 to 1000 --- 1 F001 10
CAEB Direct Input/Output Channel 2 Unreturned Messages Alarm
Events
0 to 1 --- 1 F102 0 (Disabled)
CAEC Reserved (4 items) 1 to 1000 --- 1 F001 10
Remote Devices (Read/Write Setting) (16 modules)
CB00 Remote Device 1 GSSE/GOOSE Application ID (GOID) --- --- --- F209 “Remote Device
1“
CB21 Remote Device 1 GOOSE Ethernet APPID 0 to 16383 --- 1 F001 0
CB22 Remote Device 1 GOOSE Dataset 0 to 16 --- 1 F184 0 (Fixed)
CB23 Remote Device 1 in PMU Scheme 0 to 1 --- 1 F126 0 (No)
CB24 Reserved 0 to 3 --- 1 F626 0 (None)
CB25 ...Repeated for Device 2
CB4A ...Repeated for Device 3
CB6F ...Repeated for Device 4
CB94 ...Repeated for Device 5
CBB9 ...Repeated for Device 6
CBDE ...Repeated for Device 7
CC03 ...Repeated for Device 8
CC28 ...Repeated for Device 9
CC4D ...Repeated for Device 10
CC72 ...Repeated for Device 11
CC97 ...Repeated for Device 12
CCBC ...Repeated for Device 13
CCE1 ...Repeated for Device 14
CD06 ...Repeated for Device 15
CD2B ...Repeated for Device 16
Remote Inputs (Read/Write Setting) (32 modules)
CFA0 Remote Input 1 Device 1 to 32 --- 1 F001 1
CFA1 Remote Input 1 Bit Pair 0 to 96 --- 1 F156 0 (None)
CFA2 Remote Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
CFA3 Remote Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
CFA4 Remote Input 1 Name 1 to 64 --- 1 F205 “Rem Ip 1”
CFAA ...Repeated for Remote Input 2
CFB4 ...Repeated for Remote Input 3
CFBE ...Repeated for Remote Input 4
CFC8 ...Repeated for Remote Input 5
CFD2 ...Repeated for Remote Input 6
CFDC ...Repeated for Remote Input 7
CFE6 ...Repeated for Remote Input 8
CFF0 ...Repeated for Remote Input 9
CFFA ...Repeated for Remote Input 10
D004 ...Repeated for Remote Input 11
D00E ...Repeated for Remote Input 12
D018 ...Repeated for Remote Input 13
D022 ...Repeated for Remote Input 14
D02C ...Repeated for Remote Input 15
D036 ...Repeated for Remote Input 16
D040 ...Repeated for Remote Input 17
Table B–10: MODBUS MEMORY MAP (Sheet 62 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
