B-76 F60 Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
D955 ...Repeated for DCmA Inputs 24
DNP/IEC Points (Read/Write Setting)
D968 DNP/IEC 60870-5-104 Binary Input Points (256 items) 0 to 4294967295 --- 1 F300 0
DB68 DNP/IEC 60870-5-104 Analog Input Points (256 items) 0 to 65535 --- 1 F600 0
Synchrocheck (Read/Write Setting) (4 modules)
DC70 Synchrocheck 1 Function 0 to 1 --- 1 F102 0 (Disabled)
DC71 Synchrocheck 1 V1 Source 0 to 5 --- 1 F167 0 (SRC 1)
DC72 Synchrocheck 1 V2 Source 0 to 5 --- 1 F167 1 (SRC 2)
DC73 Synchrocheck 1 Maximum Voltage Difference 0 to 400000 V 1 F060 10000
DC75 Synchrocheck 1 Maximum Angle Difference 0 to 100 degrees 1 F001 30
DC76 Synchrocheck 1 Maximum Frequency Difference 0 to 2 Hz 0.01 F001 100
DC77 Synchrocheck 1 Dead Source Select 0 to 5 --- 1 F176 1 (LV1 and DV2)
DC78 Synchrocheck 1 Dead V1 Maximum Voltage 0 to 1.25 pu 0.01 F001 30
DC79 Synchrocheck 1 Dead V2 Maximum Voltage 0 to 1.25 pu 0.01 F001 30
DC7A Synchrocheck 1 Live V1 Minimum Voltage 0 to 1.25 pu 0.01 F001 70
DC7B Synchrocheck 1 Live V2 Minimum Voltage 0 to 1.25 pu 0.01 F001 70
DC7C Synchrocheck 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
DC7D Synchrocheck 1 Events 0 to 1 --- 1 F102 0 (Disabled)
DC7E Synchrocheck 1 Block 0 to 4294967295 --- 1 F300 0
DC80 Synchrocheck 1 Frequency Hysteresis 0 to 0.1 Hz 0.01 F001 6
DC81 ...Repeated for Synchrocheck 2
DC92 ...Repeated for Synchrocheck 3
DCA3 ...Repeated for Synchrocheck 4
Phasor Measurement Unit Basic Configuration (Read/Write Setting)
DCB4 PMU 1 Function 0 to 1 --- 1 F102 0 (Disabled)
DCB5 PMU 1 LDInst --- --- --- F214 "PMUx"
DCD6 PMU 1 IDCode 1 to 65534 --- 1 F001 1
DCD7 PMU 1 STN --- --- --- F203 "GE-UR-PMU"
DCDF PMU 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
DCE0 PMU 1 Class 0 to 2 --- 1 F549 1 (M-CLASS)
DCE1 PMU 1 Format 0 to 1 --- 1 F547 0 (Integer)
DCE2 PMU 1 Style 0 to 1 --- 1 F546 0 (Polar)
DCE3 PMU 1 Rate 0 to 13 --- 1 F544 4 (10/sec)
DCE4 PMU 1 PHS-x (14 items) 0 to 14 --- 1 F543 1 (Va)
DCF2 PMU 1 PHS-x Name (14 items) --- --- --- F203 "GE-UR-PMU-
PHS 1 "
DD62 PMU 1 A-CH-x (16 items) 0 to 65535 --- 1 F600 0
DD72 PMU 1 A-CH-x (16 items) --- --- --- F203 "AnalogChannel 1
"
DDF2 PMU 1 D-CH-x (16 items) 0 to 4294967295 --- 1 F300 0
DE12 PMU 1 D-CH-x Name (16 items) --- --- --- F203 "Dig Channel 1 "
DE92 PMU 1 D-CH-x Normal State (16 items) 0 to 1 --- 1 F108 0 (Off)
DEA2 PMU 1 Reserved (16 items) 0 to 1 --- 1 F001 0
Phasor Measurement Unit Aggregator (Read/Write Setting)
E8A8 PMU Aggregator 1 Name --- --- 1 F209 "MSVID 1 "
E8C9 Aggregator 1 IDcode 1 to 65534 --- 1 F001 1
E8CA Aggregator 1 Protocol 0 to 2 --- 1 F548 0 (NONE)
E8CB Aggregator 1 TCP Port 0 to 65534 --- 1 F001 4712
E8CC Aggregator 1 UDP Port 0 to 65534 --- 1 F001 4713
E8CD PMU Aggregator 1 90-5 UDP Port 0 to 65534 --- 1 F001 102
E8CE PMU Aggregator 1 PDC Network Control 0 to 1 --- 1 F102 0 (Disabled)
E8CF Aggregator 1 Include PMU1 0 to 1 --- 1 F126 0 (No)
E8D0 Aggregator 1 Include PMU2 0 to 1 --- 1 F126 0 (No)
E8D1 Aggregator 1 Include PMU3 0 to 1 --- 1 F126 0 (No)
E8D2 Aggregator 1 Include PMU4 0 to 1 --- 1 F126 0 (No)
Table B–10: MODBUS MEMORY MAP (Sheet 68 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
