GE Multilin F60 Feeder Protection System B-83
APPENDIX B B.4 MEMORY MAPPING
B
F126
ENUMERATION: NO/YES CHOICE
0 = No, 1 = Yes
F127
ENUMERATION: LATCHED OR SELF-RESETTING
0 = Latched, 1 = Self-Reset
F128
ENUMERATION: CONTACT INPUT THRESHOLD
0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC
F129
ENUMERATION: FLEXLOGIC TIMER TYPE
0 = millisecond, 1 = second, 2 = minute
F131
ENUMERATION: FORCED CONTACT OUTPUT STATE
0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze
F132
ENUMERATION: DEMAND INTERVAL
0 = 5 min, 1 = 10 min, 2 = 15 min, 3 = 20 min, 4 = 30 min,
5 = 60 min
F133
ENUMERATION: PROGRAM STATE
0 = Not Programmed, 1 = Programmed
870 RTD Input 22
871 RTD Input 23
872 RTD Input 24
873 RTD Input 25
874 RTD Input 26
875 RTD Input 27
876 RTD Input 28
877 RTD Input 29
878 RTD Input 30
879 RTD Input 31
880 RTD Input 32
881 RTD Input 33
882 RTD Input 34
883 RTD Input 35
884 RTD Input 36
885 RTD Input 37
886 RTD Input 38
887 RTD Input 39
888 RTD Input 40
889 RTD Input 41
890 RTD Input 42
891 RTD Input 43
892 RTD Input 44
893 RTD Input 45
894 RTD Input 46
895 RTD Input 47
896 RTD Input 48
900 User-Programmable Pushbutton 1
901 User-Programmable Pushbutton 2
902 User-Programmable Pushbutton 3
903 User-Programmable Pushbutton 4
904 User-Programmable Pushbutton 5
905 User-Programmable Pushbutton 6
906 User-Programmable Pushbutton 7
907 User-Programmable Pushbutton 8
908 User-Programmable Pushbutton 9
909 User-Programmable Pushbutton 10
910 User-Programmable Pushbutton 11
911 User-Programmable Pushbutton 12
912 User-Programmable Pushbutton 13
913 User-Programmable Pushbutton 14
914 User-Programmable Pushbutton 15
915 User-Programmable Pushbutton 16
920 Disconnect switch 1
921 Disconnect switch 2
922 Disconnect switch 3
923 Disconnect switch 4
924 Disconnect switch 5
925 Disconnect switch 6
926 Disconnect switch 7
927 Disconnect switch 8
928 Disconnect switch 9
Bitmask Element
929 Disconnect switch 10
930 Disconnect switch 11
931 Disconnect switch 12
932 Disconnect switch 13
933 Disconnect switch 14
934 Disconnect switch 15
935 Disconnect switch 16
968 Breaker 1
969 Breaker 2
980 Breaker restrike 1
983 Incipient cable fault detector 1
984 Incipient cable fault detector 2
1012 Thermal overload protection 1
1013 Thermal overload protection 2
1014 Broken conductor detection 1
1015 Broken conductor detection 2
1016 Broken conductor detection 3
1017 Broken conductor detection 4
1020 Wattmetric 1
1021 Wattmetric 2
Bitmask Element
