H.1 CHANGE NOTES APPENDIX H
H
Table H–7: MAJOR UPDATES FOR F60 MANUAL REVISION Y2
PAGE
(Y1)
PAGE
(Y2)
CHANGE DESCRIPTION
All All Update Minor changes throughout document
All All Delete Deleted CPU options U and V
1-1 1-1 Update Updated Figure 1-1 Rear Nameplate
2-4 2-4 Update Updated Table 2-4 Order Codes for reduced size vertical units to indicate that modules 8L and 8N
cannot be ordered with module 8Z
2-9 2-9 Update Updated Table 2-8 Order Codes for vertical unit replacement modules to indicate that modules 8L
and 8N cannot be ordered with module 8Z
3-8 3-8 Update Updated Figure 3-10 Rear Terminal View
Table H–8: MAJOR UPDATES FOR F60 MANUAL REVISION Y1 (Sheet 1 of 2)
PAGE
(X2)
PAGE
(Y1)
CHANGE DESCRIPTION
All All Delete Deleted content pertaining to Ethernet switch
Title Title Update Changed part numbers. Updated address and contact information.
1-1 1-1 Update Updated address and contact information
2- 2- Add Added CPU options T,U, and V to order code table
2- 2- Delete Removed E, G, H, J, S from CPU options from order code tables
2-8 2-8 Delete Deleted 9S, 2S, 2T from replacement module order code Tables 2-7 and 2-8
3-10 3-10 Update Updated Figures 3-12 and 3-13 Typical Wiring Diagrams
2-19 2-19 Update Updated Ethernet fiber table in section 2.2.8 Communications
3-24 3-24 Update Deleted references to COM 1 RS485 port in section 3.2.9 CPU Communication Ports. Revised
text and Figure 3-26 CPU Module Communications Wiring to include only modules T, U, V in
section 3.2.9a.
5-1 5-1 Update Updated the front panel main menu to include the CyberSentry security menu
5-16 5-16 Update Update Communications main menu to remove the SNTP Protocol submenu
5-16 5-16 Delete Deleted references to COM 1 RS485 port in section 5.2.4b Serial Ports
5-17 5-17 Add Added section 5.2.4c Ethernet Network Topology
5-17 5-17 Update Updated Networks section 5.2.4d to include all three Ethernet ports
5-17 5-17 Update Added 0 as valid number to section 5.2.4e Modbus Protocol section
5-40 5- Delete Deleted Local Time Offset, Daylight Savings Time, DST (start/stop for month/day/hour) from Real
Time Clock menu
5- 5-40 Add Added submenus Precision Time Protocol, SNTP Protocol, and Local Time and Synchronizing
Source settings to Real Time Clock menu
5- 5-41 Add Added new Precision Time Protocol (1588) menu and setting descriptions
5- 5- Update Changed Communication to Real Time Clock in SNTP protocol settings path. Moved SNTP
Protocol menu and settings descriptions to Real Time Clock subsection
5-37 5- Delete Deleted section k) SNTP Protocol and the settings descriptions
5- 5-44 Add Added new section for Local Time menu settings and settings description
5- 5-55 Add Added new PTP Fail menu item to the User-Programmable Self Tests menu
5- 5- Add Added PTP Failure and CLOCK UNSYNCHRONIZED to Flexlogic Operands table
5-96 5-96 Update Updated PMU main menu to add aggregator and control block menu items
5- 5-96 Add Added UR Synchrophasor Implementation of IEC61850-90-5 to the PMU software option
description
5-96 5-96 Update Updated Figure: Complete Synchrophasor Implementation
5- 5-97 Add Added Figure: N60 Support For Four Logical Device PMU
5-97 5-97 Update Updated Table: Implementation By Model Number
5- 5-98 Add Added Figure: Logical Nodes Supported In Each Logical Device
